Overview
Wall Liner– 1x12.5 GM on one side of a 50 UC frame
System components
- 13 mm Gypsemna glass mat board One layer on RS
- GI L-angle 25x25, 0.50 mm At corner
- Gyp 50 mm x 0.50 mm wall stud - 3.0m As bracing max 1.0 mtr
- Gyp 50 mm x 0.50 mm wall stud - 3.0m 600 mm centers
- Wedge anchor - 6x40 mm For bracing anchor
- Waferhead screw M4.2 x 13 Metal-to-metal fixing
- Self tapping screw M3.5 x 25 mm For board fixing
- Jointing tape - Fibre For joint finishing
- Jointing compound - Exterior For joint finishing
- Rock wool 100mm thick - 70kg/m3 - to be provided by others Thermal insulation
Overview
WallLiner– 1x12.5MR on one side of a 50 UC Frame
System components
- 13 mm Gypsemna moisture-resistant board H1 One layer on RS
- GI L-angle 25x25, 0.50 mm at corner
- Gyp 50 mm x 0.50 mm wall stud - 3.0m As bracing max 1.0 mtr
- Gyp 50 mm x 0.50 mm wall stud - 3.0m 600 mm centers
- Wedge anchor - 6x40mm For bracing anchor
- Waferhead screw M4.2 x13 Metal-to-metal fixing
- Self tapping screw M3.5 x 25mm for board fixing
- Jointing tape - Fibre For joint finishing
- Jointing compound - Exterior For joint finishing
- Rockwool 100mm thick - 70kg/m3 - to be provided by others Thermal insulation
